General Specifications Power rating 160Wrms || Continuous power rating 2120W || Nominal impedance 8Ω || Frequency range 1000-20,000Hz || Sensitivity 3110dB || Recommended min. crossover (12dB/oct) 2000Hz 12dB/oct || Voice coil diameter 44mm/1.75in || Voice coil material Edgewound Copper Clad Aluminium || Magnet type Ferrite || Diaphragm material Polyimide || Surround material Polyimide
Mounting Information Width 120mm/4.72in || Depth 53mm/2.08in || Weight 2.3kg/5.1lb || Fitting Flange (2/3 M6 holes on 76/57.2, 3.0/2.224in PCD) || Throat exit 25.4mm/1.0in || Packed Dimensions & Weight Single pack size W x D x H 140mm x 170mm x 70mm || /5.5in x 6.7in x 2.8in || Single pack weight 3kg/6.6lb
Features Include 1" exit, ferrite magnet compression driver with 1.75" edgewound copper clad aluminium voice coil || 60Wrms power handling (AES standard) and 110dB sensitivity
Sound Castle clamping ensures even pressure on diaphragm assembly for reduced distortion || One piece Polyimide diaphragm and surround || Finite Element Analysis (FEA) used to optimize both magnet assembly and acoustic design
Compatible Horns H1-9040P, H1-7050 ‘No Bell’
